Specifications

Area ClassificationExplosion Proof, Intrinsically Safe, Non-incendive, General Purpose, Flame Proof

CertificationsCSA, FM, ATEX, IECEx, CUTR, Regional

Communication Protocol4-20mA Analog

Data InterfaceWired

DiagnosticsNo

Input SignalElectric

Max Outlet Pressure35 psig

Mounting TypeRemote Mount, Actuator Mount

Operating TemperatureStandard Temperature

Position ControlModulating Control

Power SourceLocal

Supply MediaAir

Other ConfigurationsContact your local Emerson business partner or sales office to learn about additional specifications or options for this product.

Features

The low-mass pilot stage, mechanically damped deflector bar, and rugged construction provide stable performance in vibration.

Large diameter nozzles, free-flow pilot stage design, and large internal pneumatic supply passages provide excellent tolerance to reducing the effects of contaminant build-up and erosion.

The electronic feedback control network monitors the pneumatic output signal, detects any input-output deviations and corrects them.

Major mechanical and electrical components are incorporated into a single field-replaceable master module.

With Stroke Port, a constant bleed from the pilot stage vents through a hole in the module cover. Covering the hole increases the transducer output to confirm the proper operation of the pilot and booster stages and stroke the actuator.
