Fluke 718ex Safe Pressure Calibrator
Fluke 718EX- Intrinsically Safe Pressure Calibrator
Applications
Pressure instrument calibration
Pressure instrument Maintenance
Petro-Chemical
Oil and Gas
Pharmaceutical
Water and wastewater
Food and Beverage
Power Generation
The new Fluke 718Ex Intrinsically Safe Pressure Calibrator is a new, powerful intrinsically safe, self contained pressure calibrator for usage in Explosion endangered areas.
Product Parameters
| Fluke 718Ex 30G Range: | -830 mbar to 2 bar (internal sensor) Over pressure: 3x FS |
| Resolution: | 0.0001 bar |
| Accuracy: | 0.05% FS |
| Functions: | Zero, Min, Max, Hold, Damp Note: for use with non-corrosive gasses |
| Fluke 718Ex 100G Range: | -830 mbar to 7 bar (internal sensor) Over pressure: 2x FS |
| Resolution: | 0.001 bar |
| Accuracy: | 0.05% FS |
| Functions: | Zero, Min, Max, Hold, Damp Note: for use with non-corrosive gasses |
| Fluke 718Ex 300G Range: | -830 mbar to 20 bar (internal sensor) Over pressure: 375 psi, 25 bar |
| Resolution: | 0.0001 bar |
| Accuracy: | 0.05% FS |
| Functions: | Zero, Min, Max, Hold, Damp Note: for use with non-corrosive gasses |
Key Features
- ATEX II 1G Ex ia IIC T4 Compliant.
- Built-in pressure / vacuum hand pump, with fine adjust vernier and bleed valve.
- 30, 100, and 300 psi ranges (2, 7, and 20 bar)
- Pressure measurement to 0.05% of full span, using an internal pressure sensor.
- Pressure measurement to 200 bar using any of eight intrinsically safe Fluke 700PEx Pressure Modules.
- Wide range of selectable measurement units for pressure.
- Current measurement with 0.02% accuracy and 0.001 mA resolution.
- Pressure switch test function.
- Min-Max Hold functions.
- Compact size and weight.
- Simple, push-button user interface.
- Rugged and reliable, ideal for field use
- Applications
- Pressure instrument calibration
- Pressure instrument Maintenance
- Petro-Chemical
- Oil and Gas
- Pharmaceutical
- Water and wastewater
- Food and Beverage
- Power Generation
- Applications
- Pressure instrument calibration
- Pressure instrument Maintenance
- Petro-Chemical
- Oil and Gas
- Pharmaceutical
- Water and wastewater
- Food and Beverage
- Power Generation
- The new Fluke 718Ex Intrinsically Safe Pressure Calibrator is a new, powerful intrinsically safe, self contained pressure calibrator for usage in Explosion endangered areas.Product Parameters
Fluke 718Ex 30G
Range:-830 mbar to 2 bar (internal sensor)
Over pressure: 3x FSResolution: 0.0001 bar Accuracy: 0.05% FS Functions: Zero, Min, Max, Hold, Damp
Note: for use with non-corrosive gassesFluke 718Ex 100G
Range:-830 mbar to 7 bar (internal sensor)
Over pressure: 2x FSResolution: 0.001 bar Accuracy: 0.05% FS Functions: Zero, Min, Max, Hold, Damp
Note: for use with non-corrosive gassesFluke 718Ex 300G
Range:-830 mbar to 20 bar (internal sensor)
Over pressure: 375 psi, 25 barResolution: 0.0001 bar Accuracy: 0.05% FS Functions: Zero, Min, Max, Hold, Damp
Note: for use with non-corrosive gasses
The new Fluke 718Ex Intrinsically Safe Pressure Calibrator is a new, powerful intrinsically safe, self contained pressure calibrator for usage in Explosion endangered areas.Product ParametersFluke 718Ex 30G
