Specifications

WarrantyUp to 15-year limited warranty

RangedownUp to 200:1

Communication Protocol4-20 mA HART™, WirelessHART®, FOUNDATION™ Fieldbus

Measurement RangeUp to 2000 psi (138 bar) differential, Up to 6092 psi (420 bar) static

Process Wetted Material316L SST, Alloy C-276, Tantalum, Gold-plated 316L SST

DiagnosticsBasic Diagnostics

Certifications/ApprovalsNSF, NACE™, hazardous location, see full specs for complete list of certifications

Features

Measures multiple variables and standardizes on a single model number for streamline process and cost-efficiency

Reduces costs by eliminating the need for stacked transmitters and additional wiring

Primary elements available as assemble-to options for simple installation and commissioning

Multivariable design reduces pipe penetrations, impulse piping and connection systems for cost-savings

Callendar-Van Dusen sensor matching improves temperature accuracy enabling best-in-class flow calculations

All-welded, SuperModule™ design offers industry-leading accuracy in harsh environments and applications

Engineering Assistant Software allows for configuration in two easy steps

Ultra for Flow provides optimized flow readings with a ±0.04% of reading accuracy

Designed with built-in flow calculations for direct reporting of fully-compensated mass, energy or volumentric flow
